Description
Stainless steel seamless eccentric reducer, larger side 76.1 × 5.6 mm, smaller side 33.7 × 4.5 mm, steel grade 1.4401 / 1.4404 / 316 / 316L. Theoretical weight per piece: 0.9 kg. An eccentric reducer transitions from DN65 to DN25 with the bottom edge kept on a single line — this prevents air pockets and dead zones from forming in horizontal pipework runs. Used in water, drainage, transfer, chemical, food-grade and sanitary installations, in pumping stations and on the suction side of centrifugal pumps. The seamless construction delivers high pressure resistance and excellent corrosion resistance.
Grade 1.4404 / 316L is an austenitic stainless steel with enhanced corrosion resistance, particularly in more chemically aggressive environments. Thanks to its molybdenum content, this grade offers better corrosion resistance than steel 1.4301 / 304. The material is used in the chemical, food, marine, pharmaceutical industries and in installations and equipment exposed to moisture, chlorides and other corrosive agents.
Technical data
| Outside diameter (OD) | DN65 / 76.10 mm |
| Wall thickness (WT) | 5.60 mm |
| Outside diameter 2 | DN25 / 33.70 mm |
| Wall thickness 2 | 4.50 mm |
| Steel grade | 1.4404 |
| 3.1 certificate available | Yes |
| Weight | 0.9 kg |
| Product code | S-RDE-MZ2/076.10X05.60/033.70X04.50/1.4404 |
